CSS has partnered with Tagit SA Group – a high-tech private Multi-National company with headquarters in Switzerland. Tagit’s range of products covers all the needs of our customers – from retail, leisure and library sectors to security paper, all needing an Electro-Magnetic (EM) detection system and labels.
Tagit has introduced to the market a new state-of-the-art system, which thanks to the innovative operation principle provides extremely high detection rates over 90%.
TAGIT EM EAS Systems are manufactured using high quality materials. Its patented 3D detection produces high level detection in all three label orientations with an enhanced aisle width of up to 110cm – subject to the configuration and onsite electrical noise level. They have been designed to meet the exit protection needs of a wide range of applications including: high-end cosmetic stores, libraries, archives, book stores, pharmacies, wine shops, galleries etc.
Please select one of these antennas based upon your needs:
The TAGIT Fortuna EM EAS System is manufactured using high quality materials, and employs our patented 3D detection technology to provide an installation distance of up to130cm with a high level detection in all three label orientations.
This system is designed for the protection of confidential/valuable documents within high-tech companies, government institutions, libraries, archives and retail applications.
Fortuna - Color
Technical Specifications
Dimensions
modifiable standard height: 157 cm | 62 inch
width: 64 cm | 25 inch
thickness of antenna frame: 2,5 cm | 1 inch
base thickness: 9 cm | 3,5 inch
Voltage
Power Consumtion
max. 130VA per antenna
TX Frequency
ca. 200 Hz
Weight Master Antenna
21,2 kg
Weight Slave Antenna
Power supply
6 kg
Alarm
visual / audio signal
optional (NO/NC Relay output)
programmable sound and light alarm sequences
The TAGIT EM EAS Premium Light System is manufactured using acrylic material. It has an attractive translucent appearance, and is highly resistant to wear.
Its patented 3D detection produces high level detection in all three label orientations with an enhanced aisle width of up to 130cm – subject to the configuration and on-site electrical noise level.
Technical Specifications
Dimensions
modifiable standard height: 158 cm | 62 inch
width: 64 cm | 25 inch
base thickness: 9 cm | 3,5 inch
Voltage
Power Consumtion
max. 130VA per antenna
TX Frequency
ca. 200 Hz
Weight Master Antenna
27 kg
Weight Slave Antenna
Power supply
6 kg
Alarm
visual / audio signal
optional (NO/NC Relay output)
programmable sound and light alarm sequences
This innovative new system has been designed to meet the exit protection needs of a wide range of applications including: high-end cosmetic stores, libraries, archives, book stores, pharmacies, wine shops, galleries etc. The TAGIT EM EAS Premium System is supplied on a worldwide basis.
Technical Specifications
Dimensions
modifiable standard height: 161 cm | 63 inch
width: 67 cm | 26 inch
base thickness: 9 cm | 3,5 inch
Voltage
Power Consumtion
max. 130VA per antenna
TX Frequency
ca. 200 Hz
Weight Master Antenna
41 kg
Weight Slave Antenna
Power supply
6 kg
Alarm
visual / audio signal
optional (NO/NC Relay output)
programmable sound and light alarm sequences
This system is designed for exit and cash desk protection in cosmetic stores, libraries, archives, book stores, pharmacies and groceries. The TAGIT EM EAS Eureka System is supplied on a worldwide basis.
Technical Specifications
Dimensions
height: 159 cm | 62.5 inch
width: 70 cm | 27.6 inch
base thickness: 11 cm | 4,3 inch
Voltage
Power Consumtion
max. 130VA per antenna
TX Frequency
ca. 200 Hz
Weight Master Antenna
29.5 kg
Weight Slave Antenna
Power supply
6 kg
Alarm
visual / audio signal
optional (NO/NC Relay output)
programmable sound and light alarm sequences
Frequently Asket Questions
Yes, they can detect more effectively than other technology can do, because the operation frequency is low.
Tagit EM labels are compatible with all other EM systems, with the exception of Meto Systems, which require special Tagit labels in order to detect. For customers that have both Meto and other EM systems in place and wish to tag at DC or at the manufacturer special dual technology labels are provided which work on both types of systems.
Tagit 3D Systems can detect on all metal objects with the only exception being metal which has been magnetised.
In order to maximise detection the longer the label the better the detection is achieved. Therefore you would generally apply longer labels to larger products and shorter labels to smaller products. If the detection on smaller products still needs to improve you can also apply speciality high performance labels, like twin and power labels in order to boost the performance.
As you have the ability to be able to protect all of the high shrink items with Tagit 3D systems and labels you get a greater shrinkage reduction and therefore a much better ROI. Please contact CSS to get your ROI calculator by email.
The only products that cannot be protected are those that have magnetic properties. This makes the Tagit 3D system the most versatile on the market.
Some air conditioners, computers, special lights and Meto EM systems which are close to the Tagit 3D System. This is the same for most EAS Systems.
Ideally you would look to improve the noise environment, but if this is not possible the main benefit of the Tagit 3D System is that by using a Master-Master or Turbo configuration with sensors you have the ability to tune the system in order to maximise the performance.
Tagit 3D EM Systems have the ability to detect labels up 1.3m aisle width.
Detection can be maximised by using a master-master configuration, sometimes with Turbo and sensors, by using longer labels or by using speciality high performance labels.
